GV-GF1901 Maximize

GV-GF1901 Lector de Huella

El GV-GF Fingerprint Reader puede trabajar con GV AS-Controller y GV-ASManager para crear un sistema de control de acceso completo.

More details

GV-GF1901

El GV-GF Fingerprint Reader puede trabajar con GV AS-Controller y GV-ASManager para crear un sistema de control de acceso completo.
Con el GV-GF de la huella digital única Reader, puede inscribirse y gestionar los usuarios a través de la tarjeta Enroll Gerente suministrado y Eliminar la tarjeta junto con las tarjetas de usuario MIFARE.

Caracteristicas:

  • Works with GV-AS Controller and GV-ASManager
  • Standalone system without the need of cabling or PC
  • Access by card plus fingerprint
  • Fingerprint templates stored on the user card
  • Wiegand output 26 bits



ModelsGV-GF1901
ApplicationIndoor use only
Communication InterfaceWiegand 26, RS-485
SensorCapacitive
Sensing Area (H x W)18 x 13 mm/ 0.71 x 0.51 in
Output1 Port (240V, 2.5A)
Operation ModeFingerprint Only
Fingerprint + Card
Number of Fingerprints1,900
Card TypeISO14443A, MIFARE Class
RF Frequency13.56 MHz
RF Distance50 mm
DC PowerDC 7.5V~12V, Max 250mA
InterfaceWiegand 26
Operating Temperature0~50° C / 32~122° F
Humidity10%~90%
Dimension (H x W x D)130.0 x 54.0 x 43.0 (mm) / 5.12 x 2.13 x 1.69 (in)
